Reinforced Graphite Sheet

Product Description

ANTILEAK 802 Reinforced Graphite Sheet

Descriptions:

Reinforced Graphite Sheet is made of expanded graphite sheet, reinforced with flat steel plate, mesh steel plate, etc…

Features:

Thermal stability

High strength

No cold flow

Applications:

Reinforced Graphite Sheet is the ideal material for manufacturing all kinds of reinforced graphite gasket, engine gasket, etc…

Available dimensions:

Type

Length

(mm)

Width

(mm)

Thickness

 (mm)

Reinforced with mesh steel plate

1000, 1200

1000

1.0-3.0

Reinforced with flat steel plate

1000, 1500

1000

0.8-3.0

Technical Data:

Item

Grade A

Grade B

Grade C

Grade D

Carbon content (%)

99

99

99

98

Sulphur content (PPM)

≤500

≤1000

≤1300

≤1500

Chlorine content (PPM)

≤35

≤40

≤45

≤50

Tolerance of density (g/cm³)

±0.05

±0.05

±0.06

±0.07

Tolerance of thickness (mm)

<1±0.03;1-1.5±0.05;                                                  >1.5±0.1

Compressibility (%)

≥40 (Density 1.0g/cm³)

Recovery (%)

≥10 (Density 1.0g/cm³)
