Graphite Cut Gasket

Product Description

Production technics:

Expanded graphite is a material processed from pure natural graphite by chemical treatment and heat treatment at more than 1000℃.This is material provides outstanding heat and chemical resistance, and is excellent for gaskets with high flexibility and low creep.

General Properties:

The sealability remains almost the same throughout a range of cryogenic to high temperature (400℃). Excellent chemical resistance to almost all liquids other than strong oxidizingacids, etc… Since cold flow and creep property are minor, it is not affected byover-tightening of gasket.

Descriptions:

Graphite gasket are cut from graphite sheets or graphite sheets with metal reinforcement.

Kammprofile graphite gasket tape is a self-adhesive tape with a peel off backing and it can easily be installed to all dimensions and shapes.

Available Style:

1700

1701

1701 W

1702

    Expanded Graphite Gasket

    Graphite Gasket reinforced with Stainless Steel

    Binded Graphite Gasket reinforced with Stainless Steel

    Kammprofile Graphite Gasket


For more information, please download the Technical Data.

  • Technical Data of Expanded Graphite Gasket
    Model:1700/1701/1701 W/1702 Download
