Flexible Graphite Braided Packing

Product Description

Flexible Graphite Braided Packing

General Properties:

Material is 100% asbestos free. Low friction coefficient, good thermal conductivity high chemical resistance and high
resilience.

Construction:

Flexible Graphite Braided Packing is braided by expanded graphite yarn and cotton yarn, can be reinforced with steel
wire or mix-braided with other material under different application.

Application:

Flexible graphite packing is applicable for sealing all types of pump, valves, mixers, dampers,vessels, etc. It can be used
to seal hot water, waste water, brine, organic solvents, hydrocarbons, corrosive liquids,etc. except strong oxidizing acid
such as
fuming sulfuric acid, concentrated sulfuric acid, chromic acid, etc.


Available Model:

2001

    Flexible Graphite Braided Packing

2001 R

    Wire-reinforced Graphite Braided Packing

2001 C

    Flexible Graphite With Carbon Fiber In Corners

2001 P

    Flexible Graphite With PTFE Fiber In Corners

2002

    Expanded Graphite Packing Ring

  • Technical Data of Graphite Braided Packing
    Model:2001/2001 R/2001 C/2001 P/2002 Download
